Product Details

7kWh 280Ah 25.6V
Home Energy Storage

7kWh 280Ah 25.6V

25.6V 280Ah LiFePO4 Wall-mounted Battery

Inquiry Back

DETAILS

Product VOLFUTR 25.6V 280Ah LiFePO4 Wall-mounted Battery
Basic Specifications
  • Rated Voltage: 25.6V
  • Rated Capacity: 280Ah
  • Available Power: 7168Wh
  • Cycle Life: ≥8000 cycles at 80% depth of discharge (DOD), 25℃
Function
  • Number of parallels: It is recommended to connect 6 units in parallel (supports up to 16 units in parallel)
  • Remote data: Bluetooth (optional) / Wi-Fi
  • Protection Level: IP21
Mechanical Specifications
  • Product dimensions (L × W × H): 440 × 270 × 550 mm
  • Net weight: 60.20 kg
Charge & Discharge Specifications
  • Operating voltage range: 22.4V ~ 29.2V
  • Rated charge and discharge current: 100A
  • Peak current: 200A Continuous @ 205A 10S
  • Rated charge and discharge power: 2560W
  • Battery Management System Configuration: 8S 200A
